Twin Cage 2000KG Construction Site Rack And Pinion Hoist

Brand Name : KANGBO

Model Number : Rack And Pinion Hoist

Certification : TUV, CCC

Place of Origin : CHINA

MOQ : 1 set

Price : Negotiate

Payment Terms : T/T, L/C

Supply Ability : 150 sets per month

Delivery Time : 25-30 days

Packaging Details : export package

NAME : Rack And Pinion Hoist

Application : Construction site, building site, bridges, chimney, plants, etc.

Design : According to European Regulation

Cage : Twin Hoist Cage

Production : As per European Regulation EN 12159:2012, EN 60204-1:2006/A1:2009.

Capacity : 2,000 KG

Contact Now

Twin Hoist Cage 2,000 KG Rack And Pinion Hoist

Rack And Pinion Hoist Introduction

The overload capacity of Hollisworth building hoist can reach 4000kgs; the lifting speed can reach 36m/min, and the max. Erecting height can be as high as 450m. The hoists are widely used in construction site,power projects, metallurgical, mining, oil and chemical industries. Hollisworth also can design and produce the special kinds of lifting equipments upon the clients; requirements or special condition on the working site. We can produce the following kinds of building hoist:

Rack And Pinion Hoist Configuration


There is a small crane for conenient assembly of the construction lift.
There is the additional 'C' door at cage side for convenient loading/unloading.
Available in single or twin hoist cage configuration.
The construction rack and pinion elevators are Variable Frequency Drive (VFD), with low starting current and much less wear and tear, very smooth starting and stopping.
Manual or Automatic Controls of the hoist is optional.
Lighting inside construction elevator car is LED lamp
The construction material hoist cage roof doors are equipped with Interlock.

Rack And Pinion Hoist Technical Data

Item & Article No. SC200BD, MP-B05; SC200/200BD, MP-B06 Rack And Pinion Hoist
Payload Capacity 2,000 KG per Cage
Lifting Speed 0–36 m/min.
Max. Lifting Height 450 m
Cage Size (internal) 3.2(Length)*1.5(Width)*2.35(Height) Meter per Cage
Cage Doors 3 doors, Entry Door + Exit Door + Side Door
Motor Control FC (Frequency Control)
Engine Power 2x11 KW per Cage
Gearbox Helical Gearbox
Safety Device Type Centrifugal Brake
Power Supply Range 380–500 V, 50 or 60 Hz, 3 Phase
Type of Mast Square Column 650*650 mm with Bolted Rack
Length Mast Section 1.508 m
Rack Module 8
